Big Tex 14OA
Heavy Duty Over-The-Axle Bumperpull Trailer
Wider and stronger is the name of the game for the 14OA Heavy Duty Over-The-Axle Bumperpull Trailer. With a 102’’ wide deck and a 14,000 lbs G.V.W.R., this heavy-duty deck-over trailer is built with the space and strength that haulers demand. Available in multiple lengths (16’, 18’, 20′, 22′, and 24’) and equipped with standard 8’ slide-in ramps, the 14OA works hard for those hauling pallets and medium-weight equipment. It’s spacious and strong, and it’s ready to get the job done—are you?
Trailer Size | G.V.W.R Rating | Trailer Weight | Trailer Payload |
---|---|---|---|
102" x 16' | 14,000# | 3,250# | 10,750# |
102" x 18' | 14,000# | 3,450# | 10,550# |
102" x 20' | 14,000# | 3,650# | 10,350# |
102" x 22' | 14,000# | 3,850# | 10,150# |
102" x 24' | 14,000# | 4,050# | 9,950# |
102" x 17' + 3' | 14,000# | 3,680# | 10,320# |
102" x 19' + 3' | 14,000# | 3,890# | 10,110# |
102" x 21' + 3' | 14,000# | 4,180# | 9,820# |
Key Features
FAST AND EASY HITCHING
LOCKING STORAGE
SECURE CARGO WITH STOP RAIL & D-RINGS
INTEGRATED STORAGE TRAY & SPARE TIRE MOUNT
Equipment
BODY
Standard
Option
8" I-Beam (10#) Frame
3" x 3.5" Channel Crossmembers
Treated Pine Floor
Black Paint
Blackwood Pro Rubber Infused Lumber Floor (per linear foot)
CARGO CONTROL
Standard
Option
Stake Pockets Along Both Sides (Quantity Varies by Length)
Full Tongue Tool Box with Locking Lid
Rub Rail Along Both Sides
Extra 5/8" D-Rings
TIRE/WHEEL
Standard
Option
ST235/80 R-16 Load Range E Radial Tires
Tire Upgrade (ST235/80 R-16 LR-G)
8-Lug
Spare Tire Mount in Toolbox
Spare Tire & Wheel (ST235/80 R-16 LR-E)
Spare Tire Upgrade (ST235/80 R-16 LR-G)
POWER
Standard
Option
7-Way RV
Sealed, Modular Cold-Weather Wiring Harness
SAFETY
Standard
Option
1/4” Grd. 70 w/Safety Latch Hook (2 each)
Complete Breakaway System w/ Zip Breakaway Cable
LIGHTS
Standard
Option
L.E.D. D.O.T. Stop, Tail, Turn & Clearance
JACKS
Standard
Option
12,000# Drop Leg Jack (Top Wind), Bolt-On
RAMPS
Standard
Option
5’ HD Stand Up Ramps (Standard Equipped on "+3" Models)
8’ Slide In Ramp Package
AXLES
Standard
Option
2 - 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs
Multi-Leaf Slipper Spring w/ Equalizer
BRAKES
Standard
Option
Forward Self-Adjusting Electric Brakes on All Hubs
COUPLERS
Standard
Option
2-5/16" Ball, Adjustable Demco EZ Latch Coupler
Adjustable Pintle in Channel in Lieu of Coupler
