Big Tex 14TL, Tilt, 83" x 20', 14K
Heavy Duty Tilt Bed Equipment Trailer
- New
List Price
$7,784
Cash Price*
$7,505
Pay As Low As $249.31 / month
*Cash, finance or wire transfer price.
Applicable taxes and fees not included
Product Highlights
Year: 2024
Model: 14TL-20BK
Axle: Tandem
GVWR: 14000 lbs
Cargo Capacity: 10540 lbs
Hitch Type: Bumper Pull
Length: 20''
Color: Black
VIN: 343657
Jack: 12,000# Drop-Leg Jack (Side Wind)|Dual Jacks on Gooseneck Model
Tires: ST235/80 R-16 Load Range E Radial Tires
CUSTOMIZE YOUR PAYMENT
Big Tex 14TL 7x20, treated floor, powder coated, 14000# GVWR, rub rail with stake pockets, 6 drings, wrap around tongue, 12K drop led jack, front stop rail, cambered 4" drop axle, 14ga double square broke diamond plate fenders, single side ez pedal locking mechanism, stationary front deck, unique tow piece main frame, full 83" wide bed between fenders, tilt platform is 75" wide, hydraulic dampening cylinder, 1'4" diamond plate knife edge on rear, led lights, spare mount, radial tires, electric brakes and 3yr warranty
With a little bit of everything to keep you rolling on your equipment hauling tasks, the 14TL Heavy Duty Tilt Bed Equipment Trailer features a rear tilt deck as well as a stationary front deck. You can stay in control of your equipment with a hydraulic dampening system with a control valve for smooth loading and unloading. And with a fabricated front stop rail and expanded cargo space, you can use every inch of your bed for maximum hauling efficiency. Get ready for a new level of productivity.
| Feature | |
|---|---|
| Color | Black |
| Axle GAWR, lubrication, and Brakes and Quantity | Tandem |
| GVWR | 14000 lbs |
| Cargo Capacity | 10540 lbs |
| Length | 20'' |
| Jack | 12,000# Drop-Leg Jack (Side Wind)|Dual Jacks on Gooseneck Model |
| Tires | ST235/80 R-16 Load Range E Radial Tires |
| Brakes | Forward Self-Adjusting Electric Brakes on Both Axles |
| Suspension | Multi-Leaf Slipper Spring w/ Equalizer |
| Tongue | 6” Channel Fold Back/Wrap Tongue|10" I-Beam (XX#) Neck on Gooseneck models |
| Coupler | Round Adjustable Pin 2-5/16” on Gooseneck Model|Adjustable 2-5/16” Demco EZ Latch |
| Frame | 6" Channel |
| Cross-Members | 3" Channel on 16" Centers |
| Front Stop Rail | 3/16" Fabricated Front Stop Rail (Bumper Pull Only) |
| Floor | Treated Pine Floor |
| Fenders | 9” x 72” 14 Ga. Diamond Plate Double Square Broke w/Back (Removable) |
| Stake Pockets | Stake Pockets Along Both Sides (Quantity Varies by Length) |
| Trailer Plug | 7-Way RV |
| Lights | Recessed, Grommet-Mounted L.E.D. Lighting |
| Wiring | Sealed, Modular Cold-Weather Wiring Harness |
| Bolt Pattern | 8-Bolt |
| Wheels | Black Mod |
| Spare Mount | Front Spare Tire Mount |
| Paint Type | Professional Finish w/ Primer Standard |
| Tilt Deck Dimensions | 16'x75" Wide (83" Between Fenders) with 1/4" Diamond plate Knife Edge |
| Tilt Deck Operation | Hydraulic Dampening with Valve Control and Single Side, EZ Pedal Locking Mechanism |
| Stationary Deck Area | 4' x 83" (20' Models)|6'x 83" (22' Models) |
| Rubrail | Rub Rail Along Both Sides |
| Tie-Downs | (6) 5/8" D-Rings |
| Break-Away Kit | Complete Breakaway System w/ Zip™ Breakaway Cable and Charger |
| Tilt Deck Angle | 12° |
